Subsurface Currents

Observations of subsurface ocean velocity contribute to estimates of ocean transports of mass, heat, freshwater, and other properties on local, to regional and basin to global scales. They are essential in resolving the wind and buoyancy driven ocean circulation, and the complex vertical velocity structure, for example, in the major ocean boundary currents, tides, equatorial currents, wave propagations, ocean eddies. Vertical velocity profile information can be used to estimate the order of ocean mixing using fine-scale parameterizations of turbulent dissipation by internal wave breaking. Velocity estimates can be combined in data assimilation models to provide gridded global estimates of ocean circulation at varying temporal and spatial scales.

Geostrophic flow from Argo and Altimeter

Figure: Mean steric height of the sea surface relative to 2000 decibars (black contours at 10cm intervals) shows the pattern of flow for the Argo era (2004-2012) based on Argo profile data, updated from Roemmich and Gilson (2009). The sea surface height (SSH) trend (cm per decade, colour shading) for the period 1993-2011 is based on the AVISO altimetry ‘reference’ product (Ducet et al., 2000). Spatial gradients in the SSH trend, divided by the (latitude-dependant) Coriolis parameter, are proportional to changes in surface geostrophic velocity. For display, the mean steric contours and SSH trends are spatially smoothed over 5 degrees longitude and 3 degrees latitude.

Reference: IPCC 5th Assessment Report, WG1 Chapter 3: Ocean Observations

Source (13/12/2017): http://rstb.royalsocietypublishing.org/content/367/1593/1245

ECV Products and Requirements

These products and requirements reflect the Implementation Plan 2022 (GCOS-244).

The requirements are found in the complete 2022 ECVs Requirements document as well: ECV Subsurface Currents.

Products			Vertical Mixing
			Upper Ocean	Deep ocean
	*()**	Unit	Values
Horizontal Resolution	G	km	10
	B
	T		100
Vertical Resolution	G	m	1	10
	B
	T		10	100
Temporal Resolution	G	d	1
	B		7
	T		30
Timeliness	G	d	1
	B
	T		30
Required Measurement Uncertainty (2-sigma)	G		0.02
	B
	T		0.1
Stability	G
	B
	T

(*) Goal (G): an ideal requirement above which further improvements are not necessary. Breakthrough (B): an intermediate level between threshold and goal which, if achieved, would result in a significant improvement for the targeted application. The breakthrough value may also indicate the level at which specified uses within climate monitoring become possible. It may be appropriate to have different breakthrough values for different uses. Threshold (T): the minimum requirement to be met to ensure that data are useful

Data sources

This list provides sources for openly accessible data sets with worldwide coverage for which metadata is available. It is curated by the respective GCOS ECV Steward(s). The list does not claim to be complete. Anyone with a suitable dataset who wishes it to be added to this list should contact the abombelliwmo [dot] int (GCOS Secretariat).

National Center for Environmental Information, Global Ocean Currents Database (GOCD)

Domain:

Ocean

Subdomain:

Physical

Scientific Area:

Energy and Temperature

ECV Steward:

Maria Paz Chidichimo

Products:

Verical Mixing
